Wireless
-
Wireless mode
802.11b/g/n/ac Wave 2 (Wi-Fi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO)
-
Wi-Fi security
WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, disable auto-reconnect, 802.11w Protected Management Frames (PMF)
-
SSID/ESSID
ESSID stealth mode (Hide SSID)
-
Wi-Fi users
Up to 100 simultaneous connections
-
Wireless Connectivity Features
Wireless mesh (802.11s), fast roaming (802.11r), BSS transition management (802.11v), radio resource measurement (802.11k)
-
Wireless MAC filter
Allowlist, blocklist
-
Wireless QR code generator
Once scanned, a user will automatically enter your network without needing to input login information
-
TravelMate
Forward Wi-Fi hotspot landing page to a subsequent connected device
Ethernet
-
Ethernet
1 x RJ45 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
Network
-
Network protocols
TCP, UDP, IPv4, IPv6, ICMP, HTTP, HTTPS, SSL v3, TLS, ARP, SSH
-
DNS over HTTPS
DNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPS
-
Hotspot 2.0
Hotspot 2.0 is a Wi-Fi standard that enables seamless, secure, and automatic connection to trusted wireless networks
-
Traffic Management
Real-time monitoring, wireless signal charts, traffic usage history
Security
-
802.1x
Port-based network access control client
-
Authentication
SSH key based, HTTPS, CLI, IP & Login attempts block, time-based login blocking, built-in random password generator
-
VLAN
Tag-based VLAN separation
DATA TO SERVER
-
Protocol
HTTP(S), MQTT, Azure MQTT, Kinesis
-
Data to server
Extract parameters from multiple sources and different protocols, and send them all to a single server; Custom LUA scripting, allowing scripts to utilize the router's Data to server feature
API
-
Teltonika Networks Web API (beta) support
Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation: https://developers.teltonika-networks.com
Monitoring & Management
-
WEB UI
HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log
-
FOTA
Firmware update from server, automatic notification
-
SSH
SSH (v1, v2)
-
Email
Receive email message status alerts of various services
-
JSON-RPC
Management API over HTTP/HTTPS
-
RMS
Teltonika Remote Management System (RMS)
System Characteristics
Firmware / Configuration
-
WEB UI
Update FW from file, check FW on server, configuration profiles, configuration backup
-
FOTA
Update FW
-
RMS
Update FW/configuration for multiple devices at once
-
Keep settings
Update FW without losing current configuration
-
Factory settings reset
A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration
FIRMWARE CUSTOMISATION
-
Operating system
RutOS (OpenWrt based Linux OS)
-
Supported languages
Busybox shell, Lua, C, C++
-
Development tools
SDK package with build environment provided
-
GPL customization
You can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients’ needs
-
Package Manager
The Package Manager is a service used to install additional software on the device
Power
Physical Interfaces
-
Ethernet
1 x RJ45 port, 10/100/1000 Mbps
-
Status LEDs
1 x Power LED (can be turned off from web-UI)
-
Antennas
2 x Internal for 2.4 GHz Wi-Fi, 2 x Internal for 5 GHz Wi-Fi
-
Antennas specifications
2 x 2400 - 2500 MHz, 50 Ω, VSWR <2.7, gain < 4.9 dBi, omnidirectional
2 x 5150 - 5850 MHz, 50 Ω, VSWR <2, gain < 5.02 dBi, omnidirectional
-
Reset
Reboot/User default reset/Factory reset button
Physical Specification
Operating Environment
Regulatory & Type Approvals
-
Regulatory
CE, UKCA, FCC, IC, RCM, CB, EAC, UCRF, RoHS, REACH, WEEE, SDPPI (POSTEL)
EMC Emissions & Immunity
Additional information
|
