Overview
Dimensions
Ø118 x 111 mm (Ø4.6 x 4.4")
IR Night Vision
40 m (131 ft)
Face Recognition
✓
License Plate Recognition
✓
Smart Detections (People, Vehicles, Animals)
✓
Resolution
4K
Field of View
H: 109.9°, V: 56.7°, D: 134.1°
Audio
Two-way audio
Weatherproofing
IP66
Tamper Resistance
IK08
Mounting
Ceiling, arm, wall, pendant mount, junction box
Performance
Networking Interface
GbE RJ45 port
Video
Image Settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
Max. Frame Rate
30 FPS
Resolution
8MP 3840 x 2160 (16:9)
Optics
Sensor
1/1.8" 8MP
Lens
Fixed focal length
Night Mode
Built-in IR LED illumination and IR cut filter
Hardware
Max. Power Consumption
20W
Supported Voltage Range
42.5—57V DC
Power Method
PoE+
Processor
Quad-core Arm® Cortex®-A53 based chip
Weight
990 g (2.2 lb)
Enclosure Material
Aluminum alloy, polycarbonate
Button
(1) Factory-reset
Ambient Operating Temperature
-30 to 50º C (-22 to 122º F)
Ambient Operating Humidity
0 to 90% noncondensing
Certifications
CE, FCC, IC
NDAA Compliant
✓
Cable
Cable Connector Type
RJ45
Cable Diameter
4.5 mm (0.2")
Cable Length
30 cm (1 ft)
Jacket Material
Thermoplastic elastomer
Jacket Enclosure Dimensions
Ø20 x 70.6 mm (0.8 x 2.8")
Jacket Enclosure Material
Thermoplastic elastomer, polycarbonate, silicone rubber
Expansion Slot
MicroSD Card
Additional information
| Weight |
1.2 kg |
| Dimensions |
15 × 15 × 15 cm |
