The Ubiquiti Cloud Gateway Ultra is a powerful and compact multi-WAN gateway designed to optimize your network performance and security. Whether you’re managing a home network or a small business environment, this versatile device offers a comprehensive solution. Enjoy uninterrupted connectivity with automatic failover and load balancing across multiple internet connections. Experience smooth and secure network operations with 1 Gbps routing, integrated intrusion detection/prevention system (IDS/IPS), and advanced security features.
Features:
- Runs UniFi Network for full-stack network management
- Manages 30+ UniFi Network devices and 300+ clients
- 1 Gbps routing with IDS/IPS
- Multi-WAN load balancing
- 0.96″ LCM status display
- USB-C powered (adapter included)
Overview
Dimensions
141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
UniFi Application Suite
Network
✓
Managed UniFi Devices
30+
Simultaneous Users Connected
300+
Max. WAN Port Count
4
Default WAN Ports
(1) 2.5 GbE RJ45
IDS/IPS Throughput
1 Gbps
Form Factor
Compact desktop
Security
Stateful Firewall
✓
Application-Aware Layer 7 Firewall
✓
DPI & Traffic Identification
✓
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
✓
Content Filtering
✓
Intrusion Prevention (IPS/IDS)
✓
Ad Blocking
✓
IDS/IPS Signatures
55,000+ with CyberSecure
VLAN/Subnet-based Traffic Segmentation
✓
VPN & SD-WAN
License-Free SD-WAN
✓
Site-to-Site VPN
Site Magic
✓
IPsec
✓
OpenVPN
✓
VPN Server
Identity Endpoint One-Click VPN
✓
Teleport Zero-Configuration VPN
✓
WireGuard
✓
OpenVPN
✓
L2TP
✓
VPN Client
OpenVPN
✓
WireGuard
✓
Networking
Multi-WAN Load Balancing
✓
Dynamic Routing
OSPF
✓
Advanced QoS
✓
Multicast DNS (mDNS)
✓
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
✓
Integrated RADIUS Server
✓
RADIUS over TLS (RadSec)
✓
Additional Internet Failover with UniFi LTE Backup
✓
Internet Quality and Outage Reporting
✓
MAC Address Table Size
2,000
Policy-based WAN and VPN Routing
✓
Customizable DHCP Server
✓
IPv6 ISP Support
✓
IGMP Proxy
✓
Hardware
Max. Power Consumption
6.2W
Power Method
USB type C (5V DC/3A)
Power Supply
USB type C (5V DC/3A) (Adapter included)
Supported Voltage Range
100—240V AC
Processor
Quad-core ARM® Cortex®-A53 at 1.5 GHz
System Memory
3 GB
On-board Storage
16 GB
Weight
520 g (1.1 lb)
Enclosure Material
Polycarbonate
LCM Display
0.96" status display
Management
Ethernet Bluetooth
LEDs
Ethernet
✓
Button
(1) Factory-reset
Ambient Operating Temperature
-10 to 40° C (14 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
✓
Certifications
CE, FCC, IC
Software
Application Requirements
Mobile App
UniFi iOS™: Version 10.12.0 and later UniFi Android™: Version 10.11.2 and later
Additional information
| Weight |
0.75 kg |
| Dimensions |
15 × 12 × 7 cm |
